Peripheral boards
Table 3-124 TM2LP - SIVAPAC Connector Assignment on the Backplane
Pair
a-wire
(tip)
1
b-wire
(ring)1
SIVAPAC connector TM2LP MDFU-E Notes
1
wht/blu 1 1a
Port 1
1a
blu/wht 23 1b 1b
2
wht/ora 3 2a
Port 2
2a
ora/wht 4 2b 2b
3
wht/grn 5 3a
Port 3
3a
grn/wht 6 3b 3b
4
wht/brn 7 4a
Port 4
4a
brn/wht 8 4b 4b
5
wht/gry 9 5a
Port 5
5a
gry/wht 10 5b 5b
6
red/blu 11 6a
Port 6
6a
blu/red 12 6b 6b
7
red/ora 13 7a
Port 7
7a
ora/red 14 7b 7b
8
red/grn 15 8a
Port 8
8a
grn/red 16 8b 8b
9
red/brn 17
Free
brn/red 18
10
red/gry 19
Free
gry/red 20
11
blk/blu 24
Free
blu/blk 25
12
blk/ora 26
Free
ora/blk 27
13
blk/grn 29
Free
grn/blk 30
14
blk/brn 31
Free
brn/blk 32
15
blk/gry 34
Free
gry/blk 35
16
yel/blu 37
Free
blu/yel 38
