Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-276 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
– Loop start setting = pins 3–4 closed (default)
– Ground start setting = pins 1–2 closed
[ground start not possible for TLANI8-IM and TLANI8-BRA]
Contact assignments
Table 3-131 TLANI2, TLANI4 - Contact Assignments
Contact Connector X2 Connector
X3
Connector X4 (ALUM)
1 a, trunk 1 Not used b ALUM1: Subsc. line module con-
nection
2 b, trunk 1 a
3 a, trunk 2 b ALUM2: Subsc. line module con-
nection
4 b, trunk 2 a
5 a, trunk 3 b ALUM1: Analog telephone connec-
tion
6 b, trunk 3 a
7 a, trunk 4 b ALUM2: Analog telephone connec-
tion
8 b, trunk 4 a
Table 3-132 TLANI8:contact assignments
Contact Connector X2 Connector X4
1 a, trunk 1 a, trunk 5
2 b, trunk 1 b, trunk 5
3 a, trunk 2 a, trunk 6
4 b, trunk 2 b, trunk 6
5 a, trunk 3 a, trunk 7
6 b, trunk 3 b, trunk 7
7 a, trunk 4 a, trunk 8
8 b, trunk 4 b, trunk 8
