Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-290 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
Table 3-140 TMC16 (for selected countries only) - SIVAPAC Connector Assignment on the
Backplane
Pair
a-wire
(tip)
1
b-wire
(ring)1
SIVAPAC connector TMC16 MDFU-E Notes
1
wht/blu 1 1a
Port 1
1a
blu/wht 23 1b 1b
2
wht/ora 3 2a
Port 2
2a
ora/wht 4 2b 2b
3
wht/grn 5 3a
Port 3
3a
grn/wht 6 3b 3b
4
wht/brn 7 4a
Port 4
4a
brn/wht 8 4b 4b
5
wht/gry 9 5a
Port 5
5a
gry/wht 10 5b 5b
6
red/blu 11 6a
Port 6
6a
blu/red 12 6b 6b
7
red/ora 13 7a
Port 7
7a
ora/red 14 7b 7b
8
red/grn 15 8a
Port 8
8a
grn/red 16 8b 8b
9
red/brn 17 9a
Port 9
9a
brn/red 18 9b 9b
10
red/gry 19 10a
Port 10
10a
gry/red 20 10b 10b
11
blk/blu 24 11a
Port 11
11a
blu/blk 25 11b 11b
12
blk/ora 26 12a
Port 12
12a
ora/blk 27 12b 12b
13
blk/grn 29 13a
Port 13
13a
grn/blk 30 13b 13b
14
blk/brn 31 14a
Port 14
14a
brn/blk 32 14b 14b
15
blk/gry 34 15a
Port 15
15a
gry/blk 35 15b 15b
16
yel/blu 37 16a
Port 16
16a
blu/yel 38 16b 16b
