Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-310 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
● CAS application software states
Modem (optional)
The analog modem (S30122-X8004-X22) is an optional subboard for the TMCAS-2 card, which
is plugged into the X20 and X21 ports. This facilitates remote administration of the CAS proto-
col converter on the TMCAS-2 card (see Page 3-311).
Figure 3-104 TMCAS-2 (for selected countries only) – CAS Application Software States
Figure 3-105 TMCAS-2 (for selected countries only) – Optional Modem
Interface 1 (ISDN) active
Interface 2 (ISDN) active
Interface 1 (CAS) active
Interface 2 (CAS) active
CAS application operational (flashing display)
X21: Pin1
