Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-314 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
Front panel
Cable and connector assignment
● For connecting to the SIVAPAC connector on the backplane: Table 3-153
● For connecting to the connector panels with CHAMP jack: Table 3-154
● For connecting to the connector panels using SIPAC 1 SU connectors: Table 3-155
Figure 3-108 TMDID (for U.S. only) (S30810-Q2452-X) - Front Panel
>
To ensure sufficient shielding, provide the board with a shielding panel. For informa-
tion on mounting the shielding panel, see Section 4.1.5.3.
LEDs (green) for displaying the trunk status:
● Trunk circuit 0
● Trunk circuit 1
● Trunk circuit 2
● Trunk circuit 3
● Trunk circuit 4
● Trunk circuit 5
● Trunk circuit 6
● Trunk circuit 7
Switch
Lockout switch
