boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-325

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Table 3-159 TMDID2 (for selected countries only) - Connector Panel Assignment with

CHAMP Jacks (for U.S. only)

CHAMP jack TMDID2 Notes

1 1a 1 Ring

Port 1

26 1b 1 TIP

2 2a 2 Ring

Port 2

27 2b 2 TIP

3 3a 3 Ring

Port 3

28 3b 3 TIP

4 4a 4 Ring

Port 4

29 4b 4 TIP

5 5a 5 Ring

Port 5

30 5b 5 TIP

6 6a 6 Ring

Port 6

31 6b 6 TIP

7 7a 7 Ring

Port 7

32 7b 7 TIP

8 8a 8 Ring

Port 8

33 8b 8 TIP

Free
