System Data Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

2-6 HiPath 3000/5000 V9, Service documentation

sysdat.fm

HiPath 3000

Dimensions

Figure 2-1 HiPath 3800 Dimensions

approx. 440 mm

approx. 980 mm

approx. 430 mm
