Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-330 HiPath 3000/5000 V9, Service documentation

boards.fm

Peripheral boards

Front panel

Figure 3-113 TMEW2 - Front Panel (S30810-Q2292-X100)

To ensure sufficient shielding, provide the board with a shielding panel. For informa-

tion on mounting the shielding panel, see Section 4.1.5.3.

Two LEDs indicating the board status:

● LED (red)

● LED (green)
