Peripheral boards
Technical connection conditions
● Maximum supply current: approximately 34 mA; maximum supply voltage: approximately
40 V DC
● Ring voltage against negative supply voltage (a-wire (tip)/RING): two telephones maxi-
mum
● Range, see Section 2.7
● Loop current detection > 10 mA
● Ground button detection > 20 mA
● The transmission technology is set according to the specific country through the respec-
tively entered country code (for country initialization, see Chapter 5, “Starting Up HiPath
3000”).
4 44 a 4 8 84 a 8
45 b 4 85 b 8
Table 3-172 8SLAR Contact Assignments
RJ45 jack X2, Pin T/R ports 1-4 MW8 jack X2, Pin T/R ports 5-8
