boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-355
Nur für den internen Gebrauch Boards for HiPath 3000
Options
Interfaces
ALUM module contact assignments
Figure 3-126 ALUM4 - Interfaces (S30817-Q935-A)
>
The cable that is plugged in by default is split and is connected to the TLA and to the
4/8/16SLA board.
Table 3-173 ALUM4 - Interface Assignments (not for U.S.)
Contact Connector X3 Connector X4 Connector X6
1 R1 from trunk 1a AE1 to Stn. 1a AT1 to TLA a
2 T1 from trunk 1b BE1 to Stn. 1b BT1 to TLA b
3 R2 from trunk 2a AE2 to Stn. 2a AT2 to TLA a
4 T2 from trunk 2b BE2 to Stn. 2b BT2 to TLA b
5 R3 from trunk 3a AE3 to Stn. 3a AT3 to TLA a
6 T3 from trunk 3b BE3 to Stn. 3b BT3 to TLA b
7 R4 from trunk 4a AE4 to Stn. 4a AT4 to TLA a
8 T4 from trunk 4b BE4 to Stn. 4b BT4 to TLA b
9 – – TA4 to SLA* a
10 – – TB4 to SLA* b
11 – – TA3 to SLA* a
12 – – TB3 to SLA* b
X1
X2
X3
X4
1
8
1
8
CB side
to the tele-
Board side
ALUM module
from the CO
9 ... 16
8 ... 1
X6
