Nur für den internen Gebrauch Boards for HiPath 3000
Options
Connector assignment
Table 3-175 AMOM - 15-Pin Sub-D Plug Assignment
Pin Signal Signal description Direction
4 LWLO0_FRONT Data output on the optical fiber in-
terface
Input
5 GND Ground return path for the +5-V
power supply
Input/output
6 SCAN_IN0 Adapter test Output
7 SCAN_IN0 Adapter test Output
10 +5 V +5-V power supply Input
11 LWLI0_FRONT Data input on the optical fiber inter-
face (front)
Output
12 GND Ground return path for the +5-V
power supply
Input/output
14 +5 V +5-V power supply Input
No other pins used.
