Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-394 HiPath 3000/5000 V9, Service documentation
boards.fm
Options
STRBR contact assignments
Table 3-186 STRBR Contact Assignments
X3, Pin Signal Name Function
11 ACT4-2M Relay contact K203 (common) 2
12 ACT4-2B Relay contact K203 (NO) 2
13 ACT4-2A Relay contact K203 (NC) 2
14 ACT4-1M Relay contact K203 (common) 1
15 ACT4-1B Relay contact K203 (NO) 1
16 ACT4-1A Relay contact K203 (NC) 1
17 P12VI + 12-V optocoupler 4
18 SENSE4 Control input optocoupler 4
21 ACT3-2M Relay contact K202 (common) 2
22 ACT3-2B Relay contact K202 (NO) 2
23 ACT3-2A Relay contact K202 (NC) 2
24 ACT3-1M Relay contact K202 (common) 1
25 ACT3-1B Relay contact K202 (NO) 1
26 ACT3-1A Relay contact K202 (NC) 1
27 P12VI + 12-V optocoupler 3
28 SENSE3 Control input optocoupler 3
31 ACT2-2M Relay contact K201 (common) 2
32 ACT2-2B Relay contact K201 (NO) 2
33 ACT2-2A Relay contact K201 (NC) 2
34 ACT2-1M Relay contact K201 (common) 1
35 ACT2-1B Relay contact K201 (NO) 1
36 ACT2-1A Relay contact K201 (NC) 1
37 P12VI + 12-V optocoupler 2
38 SENSE2 Control input optocoupler 2
41 ACT1-2M Relay contact K200 (common) 2
42 ACT1-2B Relay contact K200 (NO) 2
43 ACT1-2A Relay contact K200 (NC) 2
44 ACT1-1M Relay contact K200 (common) 1
45 ACT1-1B Relay contact K200 (NO) 1
46 ACT1-1A Relay contact K200 (NC) 1
47 P12VI + 12-V optocoupler 1
48 SENSE1 Control input optocoupler 1
