Installing HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

4-56 HiPath 3000/5000 V9, Service documentation

inst_h3.fm

Installing HiPath 3800

Figure 4-31 HiPath 3800 - Connectors and Jacks on the Backplane of the Expansion Cab-

inet

X101

X102

X103

X104

X105

X109

X110

X111

X112

X113

X114

X115

X106

X209

X211

X220 –

X223

X214
