Siemens HiPath 3000 Series

To Next Page

To Previous Page

inst_h3.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

4-69

Nur für den internen Gebrauch Installing HiPath 3000

Installing HiPath 3800

Splitting and jumper strips

Figure 4-37 Assignment (Numbering) of the Splitting/Jumper Strips (view from above)

1Ea 1Sa

1Eb 1Sb

1 2 3 4 5 6 7 8 9 10 11 1612 13 14 15

1 3 5 7

9 11 13 15

Splitting strip for 16 TW (C39334-A166-A1)

Jumper strip for 25 TW (C39334-A166-A3)

231917 21

bus 1 ...

bus 8

1 2 3 4 5 6 7 8 9 10 11 1612 13 14 15

No. 25 not used

E = Receive

S = Transmit
