Siemens HiPath 3000 Series

To Next Page

To Previous Page

inst_h3.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

4-103

Nur für den internen Gebrauch Installing HiPath 3000

Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300

Figure 4-56 HiPath 3550 and HiPath 3350 - Power cable with ferrite sleeve

Ferrite sleeve

C39022-Z7000-C7

–

5mm min. 15 mm

Power cable
