Installing HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

4-106 HiPath 3000/5000 V9, Service documentation

inst_h3.fm

Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300

Figure 4-58 HiPath 3550 - Slots in the Wall Housing

Figure 4-59 HiPath 3550 - Option Adapter Long (OPAL)

Opt.1

Opt.2

Opt.3Opt.4

Opt.5

Slot 10

Slot 4

Slot 8

Slot 6

Slot 5

Slot 9

Slot 7

V. 24

Slot 2Slot 3 CBCC

OPAL

Wall

to MDF

CUC: Connection Unit Com

Slot levels

123456

The CBCC board is connected to

the optional board via a ribbon ca-

ble (OPAL) (see adjacent figure).
