sysdat.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
2-25
Nur für den internen Gebrauch System Data
HiPath 3000
Options
TMEW2 4 x x Board for providing four two-way analog tie trunk cir-
cuits with E&M signaling.
Note on compatibility in E&M networks: TMEW2 does
not support E&M interface types 1, 1B, 2, 3, and 5 on
the TIEL board.
STMD3 8 16 x x ISDN basic rate interface (BRI) board for configuring
ISDN trunks, tie trunks, and subscribers on the same
board.
There are two versions of this board:
● S
0
interfaces without power supply
● S
0
interfaces with power supply
STMI2 2 32 4 8 x x HG 1500 board for connecting the HiPath 3800 system
directly to a local IP network (Ethernet).
Table 2-9 Optional Boards for HiPath 3800
Board
Name
Capacity Coun-
try
Type/Description
ROW
USA
TMEW2 Ports per
board
4 x x In addition to its tie trunk circuit function, this board can
also be used for connecting announcement equipment
(with start/stop signaling for announcement before an-
swering).
Table 2-8 Tie Trunk Traffic Boards for HiPath 3800
Board
Name
Capacity Coun-
try
Type/Description
Ports per board
B channels per board
Boards per cabinet
Max. number of
boards per system
ROW
USA
