Introduction

Figure 6-1 HiPath 5000 RSM Multi-Node IP System

HiPath 3500

HiPath 3000

PSTN

IP Network

HiPath 3500

Central administration unit with:

● Feature Server

● Presence Manager

● Software Update Manager

● HiPath 3000/5000 Manager E

● Inventory Manager

● ...

HiPath Cordless

Office

optiPoint 500 ...

OpenStage TDM

Central resourcing of applications

(possibly installed on a separate

PC), such as:

● OpenScape Xpressions

● OpenScape Contact Center

● HiPath Fault Management

● ...

HiPath 5000 RSM

(RSM: Real-Time Services Manager)
