exup.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

9-29

Nur für den internen Gebrauch Expanding and Upgrading HiPath 3000

HiPath 3000Expanding

Connecting speakers to an analog trunk port

Figure 9-11 Connecting Speakers to an Analog Trunk Port

HiPath 3000

TML/TLA

HiPath 3000

TML/TLA

Amplifier

T/R

Active speakers

only

T/R

REAL/STRB

Starting contact
