Workpoint Clients Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
10-36 HiPath 3000/5000 V9, Service documentation
wclient.fm
OpenStage Product Family
OpenStage 40 – No
1 x OpenStage
Key Module 15
No
1 x OpenStage
Key Module 40
Yes Connecting an External Power Sup-
ply Unit (see Figure 10-19)
2 x OpenStage
Key Module 40
Ye s
1 x OpenStage BLF Yes, for Open-
Stage BLF
● OpenStage BLF up to and in-
cluding hardware output
S30817- S7406-A101-7/-A103-
2:
The external power supply unit
is connected to the BLF.
Caution: The power supply
unit used should only be used
for this purpose. Using the free
jack of the power supply unit to
power another terminal or de-
vice is not permitted and can
lead to the destruction of the
OpenStage BLF.
● OpenStage BLF, hardware re-
lease S30817-S7406-A101-8/
- A103-3 or higher:
The external power supply unit
is connected to the terminal
(see Figure 10-19).
1 x OpenStage
PhoneAdapter
Ye s
Telephone Configuration Additional pow-
er supply re-
quired?
Note
