wclient.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

10-51

Nur für den internen Gebrauch Workpoint Clients

optiPoint 410 / optiPoint 410 S and optiPoint 420 / optiPoint 420 S

Standard key assignment (default) for optiPoint 410 entry, optiPoint 410 entry S

Refer to Section 10.2.3 for information on connection and startup.

Figure 10-23 optiPoint 410 entry, 410 entry S - Standard Key Assignment

optiPoint 410 entry

Consultation hold

Redial

Message

Callback

Speed dialing

Microphone on/off

Loudspeaker

Disconnect

optiPoint 410 entry S

Programmable

Cancel

Level
