wclient.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

10-65

Nur für den internen Gebrauch Workpoint Clients

optiPoint 410 / optiPoint 410 S and optiPoint 420 / optiPoint 420 S

Standard key assignment (default) for optiPoint 420 standard, optiPoint 420 standard S

Refer to Section 10.2.3 for information on connection and startup.

Figure 10-30 optiPoint 420 standard, 420 standard S - Standard Key Assignment

optiPoint 420 standard

Service Programmable

Redial Programmable

Mailbox Programmable

Microphone on/off Programmable

Loudspeaker Programmable

Programmable

Disconnect

optiPoint 420 standard S

Loudspeaker Programmable

Redial Programmable

Caller list Programmable

Programmable Programmable

Cancel

Level
