Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-80 HiPath 3000/5000 V9, Service documentation

wclient.fm

optiPoint 600 office

Default key assignment for optiPoint 600 office

Connection and configuration

Connection of optiPoint 600 office over the U

P0/E

interface: Refer to Page 10-90 for more infor-

mation.

Figure 10-35 optiPoint 600 office - Default Key Assignment

optiPoint 600 office

Service Programmable

Redial Programmable

Microphone on/off Programmable

Loudspeaker Programmable

Programmable

Disconnect
