wclient.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

10-99

Nur für den internen Gebrauch Workpoint Clients

optiPoint 500

Example of a Host-Client Configuration

Figure 10-48 Example a Host-Client Configuration

Local power

supply (optio-

MW wall outlets

P0/E

to the system,

2-wire, up to 1000 m (3280 feet) U

P0/E

, 4-wire, up to 100 m (328

optiPoint 500 telephone with optiPoint

phone adapter

Client

Host

optiPoint 500 telephone

MW wall outlet

Local power

supply (optio-
