Multi-SLC and System-Wide Networking
Networked HiPath 3000 systems feature
● max. 64 networked systems
● accessible using a shared station number (roaming among the systems/nodes)
● call interruption when changing between systems/nodes
Figure 11-3 Example: Cordless Extension Connection in Networked Systems
BS
SLC
BS
CorNet NQ
Home SLC
SLC-No. = 1
Station no = 124
Current location
SLC
SLC-No. = 11
Station no = 128
HiPath 3000
System 1
HiPath 3000
System 2
Extension
connection
BS
SLC
BS
SLC-No. = 2
Station number =
141
BS
SLC
BS
BS = BS3/1 or BS3/
3
A CorNet NQ connection is possible using S
0
or S
2M
lines or IP networking (see HG 1500 Administration
Manual).
