HiPath Cordless Office Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
11-12 HiPath 3000/5000 V9, Service documentation
cordless.fm
Planning Notes for Networked HiPath 3000 Systems Featuring Network-Wide Roaming
Scenario 2: Correct DECT configuration when networking HiPath 3000 systems
No incorrect handover due to identical DECT IDs despite overlapping radio areas. Disadvan-
tage: network-wide roaming not possible.
Scenario 3: Correct DECT Configuration when Networking HiPath 3000 Systems
No incorrect handover despite identical DECT IDs as the radio areas do not overlap. Network-
wide roaming possible.
Figure 11-5 Correct DECT configuration when networking HiPath 3000 systems
Figure 11-6 Correct DECT configuration when networking HiPath 3000 systems
PSTN
Networking (S
0
, S
2M
, IP)
HiPath 3000 system 1
DECT ID = 4711
HiPath 3000 system 2
DECT ID = 4712
PSTN
HiPath 3000 system 1
DECT ID = 4711
HiPath 3000 system 2
DECT ID = 4711
Networking
(S
0
, S
2M
, IP)
