CPU module
Hardware - SIMADYN D 3-3
Edition 03.2001
3
The size of the software to be loaded in the memory module (compressed to
approx. 50%) and the size of the available program memory is displayed in
CFC under the following menu item:
Target system \ Load \ Info
The program is loaded in a program memory module
MS5, 2 Mbyte Flash-EPROM, 8 Kbyte EEPROM
MS51, 4 Mbyte Flash-EPROM, 8 Kbyte EEPROM
A MS51 memory module which could be used with the PM5 may only be
used up to approx. 50 % so that the expanded code can be accepted on the
PM5.
An RS 232 interface (V.24) with service protocol DUST1 with 19.2 kbd is
permanently installed in connector X01 (9-pin sub-D socket). It is used to:
• test and commission the user program
(using CFC or "IBS")
• loading the user program from the PC (only in this module)
The connections available at the 10-pin connector X5 (8 signals and
ground) are functionally sub-divided into 2 groups, each with 4 inputs:
Pins Function
1...4 Bin. input 1...4 Absolute value
encoder 1
Incremental encoder 1
5...8 Bin. input 5...8 Absolute value
encoder 2
Incremental encoder 2
A plug-in socket is provided on the PM5 for each of the 6 functions. A
function is not selected by configuring, but by inserting a coded connector
into the associated socket.
The available connections can therefore be used for one
of the following
combinations of functions:
• 8 binary inputs or
• 4 binary inputs and 1 absolute value encoder or
• 4 binary inputs and 1 incremental encoder or
• 1 absolute value encoder and 1 incremental encoder or
• 2 absolute value encoders or
• 2 incremental encoders
Program size
MS5, MS51
Serial service
interface
Inputs
Selection
