Siemens SINAMICS Series Equipment Manual

Line Modules Booksize
3.4 Smart Line Modules (5 kW and 10 kW) with internal air cooling
Equipment Manuel for Booksize Power Modules
3-56 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Rated duty cycles of Smart Line Modules
t
P
P
max
P
n
P
s6
0.4 Pn
4 min
10 min
t
P
P
max
P
n
P
s6
0.4 Pn
10 s
60 s
t
P
P
max
P
n
10 s
0.2 s
t
P
P
n
10 s
4 s
F*P
n
Peak power duty cycle without prior loading
F: For all line modules up to ≤ 80 kW: F = 1.6
For Pn = 120 kW: F = 1.4
Peak power duty cycle with prior loading
Peak power duty cycle with prior loading
S6 load cycle with prior loading
Figure 3-30 Rated duty cycles of Smart Line Modules

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
