Siemens SINAMICS Series Equipment Manual

Line Modules Booksize
3.4 Smart Line Modules (5 kW and 10 kW) with internal air cooling
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
3-57
Derating as a function of the ambient temperature
020
[°C]
80
100
[%]
90
70
40 55
60
55
Ambient temperature
Permissible output power
Figure 3-31 Derating as a function of the ambient temperature
Derating as a function of the installation altitude
1000 2000
[m]
80
75
100
[%]
85
90
95
70
65
3000 4000
5000
60
0
Ambient temperature
Permissible output power
Figure 3-32 Derating as a function of the installation altitude
