Function modules
8.1 Technology controller
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
469
Table 8- 1 Important parameters for the level control
Parameter
Designation
Example
p1155 CI: Speed controller, speed set-
point 1
p1155 = r2294 Tec_ctrl output_sig [3080]
p2200 BI: Technology controller enable p2200 = 1 Technology controller enabled
p2253 CI: Technology controller setpoint
1
p2253 = r2224 Fixed setpoint active [7950]
p2263
Technology controller type
p2263 = 1 D component in fault signal [7958]
p2264 CI: Technology controller actual
value (X
ACTUAL
)
p2264 = r4055 [1] Analog input AI1 of TB30
p2280
Technology controller p-gain
p2280 Determine by optimization
p2285
Technology controller integral time
p2285 Determine by optimization
Function diagrams (see SINAMICS S120/S150 List Manual)
•
7950
Technology controller
- Fixed values, binary selection (r0108.16 = 1 and
p2216 = 2)
•
7951
Technology controller
- Fixed values, direct selection (r0108.16 = 1 and
p2216 = 1)
•
7954
Technology controller
- Motorized potentiometer (r0108.16 = 1)
•
7958
Technology controller
- Closed-loop control (r0108.16 = 1)
•
7959
Technology controller
- Kp/Tn adaption (r0108.16 = 1)
•
7960
Technology controller
- Controller DC link voltage (r0108.16 = 1)
Overview of important parameters (see SINAMICS S120/S150 List Manual)
Fixed setpoints
•
p2201[0...n]
CO: Technology controller fixed value 1
...
•
p2215[0...n]
CO: Technology controller fixed value 15
•
p2220[0...n]
BI: Technology controller fixed value selection bit 0
•
p2221[0...n]
BI: Technology controller fixed value selection bit 1
•
p2222[0...n]
BI: Technology controller fixed value selection bit 2
•
p2223[0...n]
BI: Technology controller fixed value selection
bit 3
