Monitoring functions and protective functions
9.5 Thermal motor protection
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
651
Terminal Modules provided the drive system with additional analog and digital data inputs
and outputs. They are intended for use in control cabinets. The Terminal Modules are
connected via DRIVE-CLiQ with the drive system. Terminal Modules TM31, TM120 and
TM150 provide inputs for temperature sensors.
● The TM31 can evaluate one temperature sensor.
● The TM120 can evaluate up to 4 temperature sensors. The sensor inputs are electrically
isolated.
● The TM150 can evaluate up to 12 sensors. The sensors can be split up into a maximum
of 3 groups. Each sensor can be freely assigned to one of the group.
Table 9- 5 Temperature sensor connection
TM120 X521 0 2 1 KTY84-1C130/PTC/PT1000/bimetallic NC
contact,
Linear motor: KTY84-1C130/PT1000
1 4 3 KTY84-1C130/PTC/PT1000/bimetallic NC
contact,
Linear motor: KTY84-1C130/PT1000
2 6 5 KTY84-1C130/PTC/PT1000/bimetallic NC
contact,
Linear motor: KTY84-1C130/PT1000
3 8 7 KTY84-1C130/PTC/PT1000/bimetallic NC
contact,
Linear motor: KTY84-1C130/PT1000
TM150 X531
1)
0 1
2
KTY84-1C130/PTC/bimetallic NC con-
X532
1)
1 1
2
KTY84-1C130/PTC/bimetallic NC con-
X533
1)
2 1
2
KTY84-1C130/PTC/bimetallic NC con-
X534
1)
3 1
3
2
4
KTY84-1C130/PTC/bimetallic NC con-
tact/PT100/PT1000
X535
1)
4 1
2
KTY84-1C130/PTC/bimetallic NC con-
X536
1)
5 1
3
2
4
KTY84-1C130/PTC/bimetallic NC con-
tact/PT100/PT1000
