Basic functions
7.30 Web server
Drive functions
448 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
Displaying messages
7.30.8.1
Displaying the diagnostic buffer
You can display the diagnostic buffer with the aid of the Web server.
The diagnostic buffer can be used to log important operating events as a logbook. The
diagnostic buffer is in the non-volatile memory, so data written to it can be read out for
subsequent analysis of a malfunction (including pre-history).
Note
You can find more detailed information on the diagnostic buffe
r in the "Diagnostic buffer"
chapter of the SINAMICS S120 Commissioning Manual with STARTER.
