Communication
11.3 Communication via PROFINET IO
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
813
Note
Support for the medium-dependent interface auto-MDI(X)
•
The Ethernet interface does not support auto-MDI(X). If the network card of the PG/PC
does not support auto-MDI(X) either, only crossed cables may be used to connect
devices.
•
The PROFINET interfaces support Auto MDI(X). It is therefore possible to use both
crossed and uncrossed cables to connect the devices.
•
The CBE20 Communication Board also supports auto-MDI(X). It is therefore possible to
use both crossed and uncrossed cables to connect the devices.
11.3.1.7
References
● The integration of a SINAMICS S120 with CU310-2 PN/CU320-2 DP/CU320-2 PN in a
PROFINET IO system is described in detail in the "SIMOTION SCOUT Communication"
System Manual.
● For an example of how to link a Control Unit to a SIMATIC S7 via PROFINET IO, please
refer to the FAQ in the Online Support "PROFINET IO communication between an S7-
CPU and SINAMICS S120
(http://support.automation.siemens.com/WW/view/en/27196655)".
● A description of the CBE20 and how you can install it is provided in the SINAMICS S120
Control Units and Additional System Components Manual.
● The PROFINET interface on the CU310-2 PN unit is described in the SINAMICS S120
AC Drive Manual:
Overview of important parameters (see SINAMICS S120/S150 List Manual)
Ethernet interface
•
p8900[0...239]
IE Name of Station
•
p8901[0...3]
IE IP Address
•
p8902[0...3]
IE De
fault Gateway
•
p8903[0...3]
IE Subnet Mask
•
p8904
IE DHCP Mode
•
p8905
IE Interface Configuration
•
r8910[0...239]
IE Name of Station actual
•
r8911[0...3]
IE IP Address actual
•
r8912[0...3]
IE Default Gateway actual
•
r8913[0...3]
IE Subnet Mask actual
•
r8915[0...5]
IE MAC Address
