Siemens SIROTEC Function Manual

Infeed
2.2 Smart Infeed
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
49
Table 2- 6 Smart Infeed status message
Signal name
Internal status word
Parameter
PROFIdrive telegram 370
Ready to start
ZSWAE.0
r0899.0
E_ZSW1.0
Ready ZSWAE.1 r0899.1 E_ZSW1.1
Operation enabled
ZSWAE.2
r0899.2
E_ZSW1.2
Fault active ZSWAE.3 r2139.3 E_ZSW1.3
No OFF2 active
ZSWAE.4
r0899.4
E_ZSW1.4
Switching on inhibited
ZSWAE.6
r0899.6
E_ZSW1.6
Alarm active
ZSWAE.7
r2139.7
E_ZSW1.7
Control requested
ZSWAE.9
r0899.9
E_ZSW1.9
Precharging completed
ZSWAE.11
r0899.11
E_ZSW1.11
Line contactor closed
ZSWAE.12
r0899.12
E_ZSW1.12
2.2.4
Function diagrams and parameters
Function diagrams (see SINAMICS S120/S150 List Manual)
•
8810
Smart Infeed overview
•
8820
Smart Infeed
- Control word, sequence control, infeed
•
8826
Smart Infeed
- Status word, sequence control, infeed
•
8828
Smart Infeed
- Status word, infeed
•
8832
Smart Infeed
- Sequencer
•
8838
Smart Infeed
- Missing enables, line contactor control
•
8850
Smart Infeed
- Interface to the Smart Infeed (control signals, actual values)
•
8860
Smart Infeed
- Signals and monitoring functions, line voltage monitoring
•
8864
Smart Infeed
- Signals and monitoring functions, line frequency and Vdc
monitoring
