Infeed
2.2 Smart Infeed
Drive functions
48 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
Note
Under the condition that the drive system was commissioned with STARTER and no
PROFIdrive
telegram was activated, the infeed can be powered up by issuing an enable
signal at the EP terminals and a positive signal edge at OFF1 (p0840).
Switching off the Smart Line Module
The Smart Line Module is switched off by the same procedure used to switch it on, but in the
reverse order.
However, there is no precharging at switch off.
Switching off the controller with the OFF1 signal is delayed by the time entered in p3490.
This allows the attached drives to be braked in a controlled manner.
Control and status messages
Table 2- 5 Smart Infeed open-loop control
Signal name
Internal
control
word
Binector input
Display of internal
control word
PROFIdrive
telegram 370
ON/OFF1
STWAE.0
p0840 BI: ON/OFF1
r0898.0
E_STW1.0
OFF2 STWAE.1 p0844 BI: 1. OFF2 and
p0845 BI: 2. OFF2
r0898.1 E_STW1.1
Enable operation
STWAE.3
p0852 BI: Enable operation
r0898.3
E_STW1.3
Inhibit regenerating STWAE.6 p3533 BI: Infeed, inhibit regenerative
operation
r0898.6 E_STW1.6
Acknowledge fault STWAE.7 p2103 BI: 1. Acknowledge faults or
p2104 BI: 2. Acknowledge faults or
p2105 BI: 3. Acknowledge faults
r2138.7 E_STW1.7
Master control by PLC
STWAE.10
p0854 BI: Master control by PLC
r0898.10
E_STW1.10
