2.3 Basic Infeed
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
55
Switching off the Basic Line Module
For switching off, carry out the steps for switching on in the reverse order. However, there is
no pre-charging at switch off.
Control and status messages
Table 2- 7 Basic Infeed open-loop control
Signal name
Internal
control word
Binector input
Display of internal
control word
PROFIdrive tele-
gram 370
ON/OFF1
STWAE.0
p0840 BI: ON/OFF1
r0898.0
E_STW1.0
OC/OFF2 STWAE.1 p0844 BI: 1st OFF2 and
p0845 BI: 2nd OFF2
r0898.1 E_STW1.1
Acknowledge fault STWAE.7 p2103 BI: 1st acknowledge faults or
p2104 BI: 2nd acknowledge faults or
p2105 BI: 3rd acknowledge faults
r2138.7 E_STW1.7
Master control by PLC
STWAE.10
p0854 BI: Master control by PLC
r0898.10
E_STW1.10
Table 2- 8 Basic Infeed status message
Signal name
Internal status word
Parameter
PROFIdrive telegram 370
Ready to start
ZSWAE.0
r0899.0
E_ZSW1.0
Ready
ZSWAE.1
r0899.1
E_ZSW1.1
Operation enabled
ZSWAE.2
r0899.2
E_ZSW1.2
Fault active
ZSWAE.3
r2139.3
E_ZSW1.3
No OFF2 active
ZSWAE.4
r0899.4
E_ZSW1.4
Switching on inhibited
ZSWAE.6
r0899.6
E_ZSW1.6
Alarm active
ZSWAE.7
r2139.7
E_ZSW1.7
Control requested
ZSWAE.9
r0899.9
E_ZSW1.9
Pre-charging completed
ZSWAE.11
r0899.11
E_ZSW1.11
Line contactor closed
ZSWAE.12
r0899.12
E_ZSW1.12
