Siemens SIROTEC Function Manual

Communication
11.1 Communication according to PROFIdrive
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
735
Interface IF1 and IF2
The CU320-2 Control Unit can communicate via two different interfaces (IF1 and IF2).
Both interfaces can be allocated the following physical interfaces:
● (1) On-board X126 PROFIBUS/X150 PROFINET
● (2) Communication Board X1400
Note
Ethernet interface X127 is intended for commissioning and diagnostics.
Do not use this i
nterface for other purposes (e.g. field bus communication) and ensure that
X127 (e.g. for service) is always accessible.
Table 11- 3 Properties of IF1 and IF2
IF1
IF2
PROFIdrive and SIEMENS
telegram
x -
Free telegram
x
x
Isochronous mode
x
x
Drive object types
All
All
Can be used for PROFINET IO, PROFIBUS DP,
SINAMICS Link, PN Gate, Ether-
net/IP
PROFINET IO, PROFIBUS DP,
CANopen, SINAMICS Link,
PN Gate, Ethernet/IP
Cyclic operation
x
x
PROFIsafe
x
x
Note
For additional information on the IF1 and IF2 interfaces, see chapter "
Parallel operation of
communication interfaces
(Page 749)" in this manual.
Connecting a PG/PC with the STARTER/Startdrive commissioning tool
The following connection options are available for commissioning a Control Unit with a
PG/PC using the commissioning tool.
● STARTER: PROFIBUS, PROFINET, or Ethernet.
● Startdrive: PROFINET or Ethernet.
