Siemens SIROTEC Function Manual

Communication
11.5 Communication via EtherNet/IP
Drive functions
878 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
Table 11- 40 Class Attribute
No.
Service
Type
Name
1
get
UINT16
Revision
2 get UINT16 Max Instance
3
get
UINT16
Num of Instances
Table 11- 41 Instance Attribute
No.
Service
Type
Name
Value/explanation
3 get Array of
UINT8
Assembly 1 byte array
Connection Management Object, Instance Number: 6 hex
Supported services
Class
•
Get Attribute all
•
Get Attribute single
I
nstance
•
Forward open
•
Forward close
•
Get Attribute single
•
Set Attribute single
Table 11- 42 Class Attribute
No.
Service
Type
Name
1
get
UINT16
Revision
2
get
UINT16
Max Instance
3
get
UINT16
Num of Instances
Table 11- 43 Instance Attribute
No.
Service
Type
Name
Value/explanation
1 get UINT16 OpenReqs Counters
2
get
UINT16
OpenFormat Rejects
Counters
3
get
UINT16
OpenResource Rejects
Counters
4
get
UINT16
OpenOther Rejects
Counters
5
get
UINT16
CloseReqs
Counters
6
get
UINT16
CloseFormat Rejects
Counters
7
get
UINT16
CloseOther Rejects
Counters
8 get UINT16 ConnTimeouts Counters
Number of bus errors
