Siemens SIROTEC Function Manual

Communication
11.6 Communication via SINAMICS Link
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
893
In this example, the first "Control Unit 1" node has two drive objects: "Drive 1" and "Drive 2".
Proceed as follows to send data:
1. If SINAMICS Link is assigned to IF1, then for each drive object, in its associated
parameter p2051[0...31], you define which data (PZDs) should be sent.
If SINAMICS Link was assigned IF2, then p8851 must be used for the setting. The data is
simultaneously reserved in the send slot of the p8871[0...31].
2. Enter the double words in p2061[x].
Double word data is simultaneously written to p8861[0...31].
3. For each drive object, allocate the send parameters in p8871[0...31] to a send slot of its
own node.
Table 11- 55 Compile send data of drive 1 (DO2)
p2051[x]
Index
p2061[x]
Index
Contents
From parame-
ter
Telegram
word p8871
0
-
ZSW1
r0899
1
- 1 Actual speed value part 1 r0061[0] 2
-
Actual speed value part 2
3
-
3
Actual torque value part 1
r0080
4
-
Actual torque value part 2
5
5
-
Actual fault code
r2131
6
6
-
0
0
0
...
-
...
-
...
15
-
0
0
0
...
-
...
-
...
31
-
0
0
0
