Receiving data
The sent telegrams of all nodes are simultaneously available at the SINAMICS Link. Each
telegram has a length of 32 PZD. Each telegram has a marker of the sender. You select
those PZD that you want to receive for the relevant node from all telegrams. You can
process a maximum of 32 PZD.
Note
If you have not deactivated the evaluatio
n of bit 10 with p2037 = 2, the first word of the
receive data (PZD
1) must be a control word, where bit 10 = 1 is set.
In this example, Control Unit 2 receives selected data from the telegram of Control Unit 1.
Proceed as follows to receive data:
1. In parameter p8872[0…31] enter the address of the node for which you want to read one
or more PZDs (e.g. p8872[3] = 1 → from node 1, read in PZD 4, p8872[15] = 0 → do not
read in PZD 16).
2. After setting the parameters, using parameter r2050[0…31] or r2060[0…31] you can read
out the values.
Table 11- 58 Receive data for Control Unit 2
From the sender
Receiver
Transfer
from
Tel. word
1)
p8871[x]
Address
p8872[x]
Receive buffer
p8870[x]
Data transferred in
Parameter
Contents
r2050[x]
r2060[x]
p2051[0]
0
1
PZD 1
0
-
r0899
ZSW1
p2061[1]
1
1
PZD 2
-
1
r0061[0]
Actual speed value part 1
2
1
PZD 3
-
r0061[0]
Actual speed value part 2
p2061[3]
3
1
PZD 4
-
3 r0080
Actual torque value part 1
4
1
PZD 5
-
Actual torque value part 2
p2051[5]
5
1
PZD 6
5
-
r2131
Actual fault code
p2051[4]
6
1
PZD 7
6
-
r0899
ZSW1
p2061[5]
7
1
PZD 8
-
7 r0061[0]
Actual speed value part 1
8
1
PZD 9
-
Actual speed value part 2
p2061[6]
9
1
PZD 10
-
9 r0080
Actual torque value part 1
10
1
PZD 11
-
Actual torque value part 2
p2051[7]
11
1
PZD 12
11
-
r2131
Actual fault code
p2051[8]
12
1
PZD 13
12
-
r2138
Control word, faults/alarms
p2061[9]
13
1
PZD 14
-
13 r0046
Missing enables part 1
14
1
PZD 15
-
Missing enables part 2
-
15
0
PZD 16
15
-
0
Empty
...
...
...
...
...
...
...
...
- 31 0 PZD 32 31 0 0 -
