Siemens SIROTEC Function Manual

Basic information about the drive system
13.6 Inputs/outputs
Drive functions
966 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
Control Unit 310-2
•
2020
CU310
-2 input/output terminals -
isolated digital inputs (DI 0 ... DI 3, DI 22)
•
2021
CU310
-2 input/output terminals -
isolated digital inputs (DI 16 ... DI 21)
•
2030
CU310
-2 input/output terminals -
digital input/outputs, bidirectional (DI/DO 8 … DI/DO 9)
•
2031
CU310
-2 input/output terminals -
digital input/outputs, bidirectional (DI/DO 10 … DI/DO 11)
•
2032
CU310
-2 input/output terminals -
digital input/outputs, bidirectional (DI/DO 12 … DI/DO 13)
•
2033
CU310
-2 input/output terminals -
digital input/outputs, bidirectional (DI/DO 14 … DI/DO 15)
•
2038
CU310
-2 input/output terminals -
digital output (DO 16)
Digital outputs
Signal processing using the digital outputs is shown in the function diagrams listed below.
Properties
● Separate power supply for the digital outputs.
● Source of output signal can be selected by parameter.
● Signal can be inverted by parameter.
● Status of output signal can be displayed
– As a binector output
– As a connector output
Note
Before the digital outputs can function, their own electronics power supp
ly must be
connected.
