4Operation Sirona Dental Systems GmbH
4.5Dentist element Operating Instructions INTEGO
4.5.14 Timer function
4.5.14.1
Timer function on the EasyPad
The
Fn
function key is assigned to the timer function.
Presetting the timer
A set time can be counted down to zero with the timer function.
The timer is preset in the
Setup
of the treatment center, see "Presetting
the timer" [ → 193].
Starting, stopping/resetting the timer
✔ The time or speed/intensity is shown on the EasyPad display.
➢ Press the
Fn
key.
The timer is started immediately. The preset time counts down on
the EasyPad display.
When the time is up, a short acoustic signal sounds.
Press again to stop the timer and reset the countdown. It can then be
restarted.
4.5.14.2
Timer function on the EasyTouch
A set time can be counted down to zero with the timer function. A time
loop (automatic restart of the countdown) and an acoustic signal (when
the set time has expired) can be added to each timer.
Presetting the timer
The maximum time setting is 9 minutes and 30 seconds.
✔ The
Start dialog
of the
highspeed handpiece
or the
sub-dialog
of an
instrument is shown on the touchscreen.
1. Press and hold the
Timer
key on the touchscreen (> 2 s).
The
Timer Function
setting dialog is displayed on the
touchscreen.
2. Use the
–
and
+
keys to set the required time.
Increments:
From 00:05 to 1:00 = 5 s steps
From 1:00 to 3:00 = 10 s steps
From 3:00 to 9:30 = 30 s steps
3. Select whether you want to switch the time loop (i.e. the timer restarts
automatically after the time is up) and the acoustic signal for the
selected timer on or off. Touch the
Time loop
and/or
Acoustic signal
key.
If a function is switched on, the corresponding key is highlighted
orange.
