5.3.4 Purging water lines manually
With the INTEGO treatment center, the purge and sanitize function is
optional. If this function is not available, purging of the water lines must
be carried out manually. The water-carrying instruments of the dentist
element, the 3-way syringe of the dentist and assistant element and the
tumbler filling must be purged.
For the purge function, individual instruments are removed from the
holder and held over the cuspidor for purging. If your treatment center is
not equipped with a cuspidor, hold the instruments over a watertight
container with sufficient capacity.
Purge the water lines of all instruments:
● Before starting work
● the used instruments after each patient
● At the end of the work day
Preparation
1. If your treatment center is equipped with a cuspidor, activate the
cuspidor flushing for at least one minute. This flushes the water lines.
2. Set all of the instruments to maximum water flow. The water
regulators under the instrument holder must be turned
counterclockwise.
Purging water lines
Purging water lines
1. Press the tumbler filler three times.
2. Hold the 3-way syringe of the dentist and assistant element over the
cuspidor or over a watertight container with sufficient capacity and
press the water key for at least 20 seconds.
3. Afterward, return the 3-way syringe back to the holder.
4. Remove a single instrument from holder and hold it over the cuspidor
or over a watertight container with sufficient capacity. For the CS
dentist element: Move the swivel arm of the instrument into working
position.
max.
max.
