Sirona Intego - Flushing the Cuspidor on the Easytouch

64 57 498 D3543
152 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.7Water unit Operating Instructions INTEGO
4.7.3.2
Flushing the cuspidor on the EasyTouch
Switching flushing on/off
➢ Press the Flushing fixed key.
 The flushing function is activated for the preset flushing time.
Setting the flushing time
1. Press and hold the Flushing key on the dentist element (> 2 s).
 The
Flushing settings screen appears on the touchscreen.
2. Set the flushing time with the + and – keys.
Linking flushing to mouth rinsing position S
➢ Touch the Link flushing to mouth rinsing position S key.
 If the key is marked orange, flushing is automatically activated for
the duration of the flushing time set when the chair is moved to
the mouth rinsing position S.
B
10:45:03
2
1
0S
S
0:45
S
