Sirona Intego - SIVISION Monitor

64 57 498 D3543
176 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.12SIVISIONdigital video system Operating Instructions INTEGO
4.12.1 SIVISION monitor
22" AC monitor
The monitor is equipped with loudspeakers. There is an IEC socket on the
back of the monitor for the power supply. Please refer to the operating
instructions for the 22" AC monitor for details.
The monitor is mounted on the lamp support rod. It can be rotated and
swiveled.
LEDlight, LEDview and LEDview Plus
Monitors that are equipped with four threaded holes at a distance of 75
mm on the rear can be mounted on the monitor holder on the LEDlight
and LEDview/LEDview
PLUS
lamp support rod (VESA standard MIS-D
75). Monitors with threaded holes at a distance of 100 mm can also be
mounted on the holder of the LEDview/LEDview
PLUS
lamp support rod
(VESA standard MIS-D 100).
Monitor, not suitable without appr oval
Connection of loudspeakers
WARNING
Monitors without approval must not be connected.
They endanger the product safety of the treatment center.
➢ Use only monitors that are approved according to IEC 60950-1,
IEC 62368-1 (office equipment) or IEC 60601-1 (medical devices).
WARNING
Unsuitable devices can be connected to the loudspeaker port of the
monitor.
The connection of unsuitable devices endangers the product safety of
the treatment center.
➢ The loudspeaker port of the monitor may be connected only to a
device that complies with IEC 60950-1, IEC 62368-1 (office
equipment such as PCs) or IEC 60601-1 (medical devices). Under
no circumstances should it be connected e.g. to a stereo system.
