Sirona Intego - SIVISION Program; Starting PC Communication

64 57 498 D3543
186 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.13Operation with a PC Operating Instructions INTEGO
4.13.1 SIVISION program
Various PC applications of the PC can be started and operated in the
SIVISION program.
You can select the PC applications to be operable via the treatment
center in SIUCOM plus. The keys displayed on the touchscreen and their
arrangement can be adjusted individually. For details, refer to the manual
"Installation and Configuration of SIUCOM plus / SIVISION connect".
The network connection of the treatment center must be configured in the
setup program before using the SIVISION program, see "Configuring the
network connection" [ → 202].
PC applications can be controlled only from the treatment center that was
started via SIUCOM plus.
4.13.1.1
Starting PC communication
Opening the SIVISION dialog
✔ All PC applications which were started from the treatment center
have been terminated.
✔ SIUCOM plus has been started, e.g. via Autostart.
➢ Touch the
SIVISION dialog key on the touchscreen.
or
➢ If intraoral images are desired: Remove the SiroCam F / AF / AF
+
intraoral camera from the holder. The SIDEXIS PC application or
SI Video starts immediately.
 The
SIVISION dialog is displayed on the touchscreen.
Starting other PC applications
1. Select the desired PC application from the left side of the
touchscreen.
 The key of the selected PC application is highlighted orange and
the corresponding control keys are displayed on the right side of
the touchscreen; see the following sections. The PC application
is automatically started on the PC.
2. The
File selection dialog opens for PC applications that can access
files of the PC. Select the desired file by touching it.
 The control keys of the relevant PC application are displayed on
the touchscreen.
