3Unit description Sirona Dental Systems GmbH
3.10Assistant element Operating Instructions INTEGO
3.10
Assistant element
The scope of functions of the assistant element is adapted to the dental
assistant's field of activity.
The INTEGO treatment center and INTEGO pro with Ambidextrous option
can be equipped with the Compact or Comfort assistant element. INTEGO
pro without the Ambidextrous option is available only with the Comfort
assistant element. The user interface on the assistant element is optional.
Compact assistant element
The Compact assistant element can be swiveled and attached directly to
the water unit.
If the Compact assistant element is attached to the water unit, the
assistant element is automatically moved away to prevent collisions when
swiveling the cuspidor. The assistant element is equipped with a safety
shutdown on the water unit Ambidextrous.
A Holders 1 to 4 (from left to right) for instruments
B User interface
C Handle
D Support arm and rotary joint
E Central suction sieve under the removable cuspidor bowl
D
C
B
A
E
