Sirona Intego - Setting the Speed on the Easytouch

64 57 498 D3543
102 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.5Dentist element Operating Instructions INTEGO
4.5.8.3
Setting the speed on the EasyTouch
Speeds are saved on the three favorite keys that can be accessed by
pressing them. Individual speeds can be saved for each user profile on
the favorite keys.
On the C
+
electronic foot control, spray activation is saved on the favorite
keys. The settings can also be made via the 4-way switch plate.
Accessing saved speed
✔ The electric motor is removed from the holder.
✔ The Motor dialog is displayed on the touchscreen.
➢ Touch one of the favorite keys in the bottom line briefly (< 1 s).
 The favorite key is highlighted orange. At the left of the favorite
keys, the selected speed is displayed in rpm (revolutions per
minute).
Electric motor, speeds on the favorite keys
By moving the 4-way switch plate of the C
+
electronic foot switch to the
right, the settings of the favorite keys can be accessed consecutively.
Changing the speed
➢ Press and hold the left or right favorite key (> 1 s).
 The speed is increased or reduced. The favorite keys are shaded
gray for intermediate values.
The speed can also be increased or reduced by moving the 4-way switch
plate of the C
+
electronic foot switch up or down.
B
10:45:03
2
1
0S
rpm
20000
1.2 4020
Set
IMPORTANT
Speeds on the favorite keys
The speed of the motor in rpm equals 1,000 times the speed shown on
the key. Example:
Key value 0.1 = 100 rpm (with eControl option)
Key value 1.2 = 1,200 rpm
Key value 20 = 20,000 rpm
Key value 40 = 40,000 rpm
Please note that the speed of the burr depends on the selected straight
or contra-angle handpiece.
S
0
rpm
28000
1.2 4020
Set
S
0
