Sirona Dental Systems GmbH 4Operation
Operating Instructions INTEGO 4.6Assistant element
båÖäáëÜ
4.6.6.6
Technical data
General Technical Data on Mini L.E.D.
Optical specification of Mini L.E.D.
1
Only composite materials can be cured which react to the stated
wavelength. The Mini L.E.D. is not suitable, e.g. for Lucirin
®
(absorption
maximum 380 nm).
Hazard distance (HD) and exposure
hazard value (EHV) according to IEC
62471
Model: Mini L.E.D.
Weight of handpiece without hose: 105 g
Dimensions: Dia. 23mm x 240mm
Current consumption of handpiece: 5 V DC / 0.65 A
Thermal safety: Overheat protection
Wavelength:
Max. intensity:
420 nm – 480 nm
1
at 450 nm
Light power dia. 7.5 mm (standard
version):
1250mW/cm
2
Light power dia. 5.5 mm (available
from Satelec):
2000 mW/cm
2
Light power: 450 mW – 500 mW
Classification acc. to IEC 62471 Risk group 2 with light bar removed
HD EHV
Blue light
Free group
907 mm 20.6
Blue light
Risk group 1
323 mm 2.6
Blue light
Risk group 2
–0.01
Thermal hazard to the
cornea
Free group
–0.97
