External device connection
External medical accessories can be connected to external device
connection. They must comply with the requirements of the Medical
Device Directive 93/42/EEC.
Additional devices, hydrogen peroxide up to 0.2‰, disinfection system, and fresh water bottle are optional
External device connection, DV GW with additional devices, disinfection system optional or with a fresh water bottle
External d evice connection, inlet connector
NOTICE
If the treatment center is equipped with a disinfection system or fresh
water bottle option, additional devices on the external device connection
are exposed to a hydrogen peroxide concentration (H
2
O
2
) of 0.1‰-
0.2‰.
If the additional devices are not suitable for the specified hydrogen
peroxide concentration, they may be damaged.
➢ Before connecting any additional devices, check to make sure that
they can be exposed to the above hydrogen peroxide concentration.
Contact the manufacturer of the relevant additional device, if
necessary.
➢ Prior to sanitation, additional devices must be unplugged from the
external device connection (water connection), see "Sanitation"
[ → 268].
IMPORTANT
DVGW approval
As the treatment center is designed according to EN 1717 (DVGW
requirements), the connected additional devices also fulfill the
requirements of the above standards when a disinfection system is
integrated or a fresh water bottle not connected to the public drinking
water supply is used, see"Standards and Approvals" [ → 23].
IMPORTANT
Self-contained power supply
The IEC socket remains live when the power switch is turned off. The
connected external devices therefore must have their own power switch.
However, the air and water connections are switched off.
